Modell inklusive elektrischem Einziehfahrwerk, Fuel-Tank und 250ml UAT, Vektor-Schubrohr und Hardware für Servos.
Die Versandkosten werden separat verrechnet, Versand über Spedition.
Specifications:
Model:
Matrix Sport Jet
Wingspan:
78.7″ (2,000mm)
Length:
87.6″ (2,225mm)
Weight:
21.9lbs (9.94kg) with 14kg turbine
FEATURES:
Extremely lightweight full composite construction especially designed for outstanding sport flight with 3D performance
Painted outside the mold so no seam lines
Ultra light weight landing gear, the 2.2m predator sport jet V2 landing gear can use to the Matrix too.
Specially designed easy access to turbine for speedy installation
Field setup can be done in seconds, thanks to the quick releases on the wings without the need for any tools.
the single elevator clamp from the top, only a few turns to tight/loose the bolt then you can install/take out the stabilizer.
Removable wing and elevator for easy transport
The equipment installation board make the electronic items with very clear installation. Most of the wire can be hidened.
pre-install tube for the stab/rudder extension wire, easy to install.
Option with vector tail pipe for 3D flight.
Included hardware:
Complete air frame (including carbon wing-tubes and preinstalled and painted fiberglass control horns)
Servo extension leads
normal tail pipe (optional Vector thrust pipe)
3.800ml fuel tank (optional upgrade to fuel bag)
250ml UAT tank
Pre-prepared pushrods with ball links
Servo connector brackets
*Also available: TR(turbine ready) version 2.2m Matrix jet with fuel tank and air trap, normal tailpipe, electric retract gear with brake, servo and hardware, preinstall the above items in factory. without wing bag/fuselage bag
*Also available: TR(turbine ready) PRO version 2.2m Matrix jet with fuel tank and air trap, vector tailpipe, electric retract gear with brake, servo and hardware, preinstall the above items in factory. with wing bag and fuselage bag
Required hardware:
Turbine size:
100-140N for normal sport flying
160-180N for 3D vector flight – Avoid high speed high G flying
Servos: Total x10 (x5 standard size + x5 medium size)
x3 standard size high torque
x2 for flaps (minimum 40kg)
x1 for rudder (minimum 40kg)
x7 medium size servo (size: 35x15x30mm)
x2 for ailerons (minimum 16kg)
x2 for elevators (minimum 16kg)
x1 for vector elevator (minimum 16kg), this is option
x1 for vector rudder (minimum 16kg), this is option
x1 for steering (minimum 10kg)
Also requires all the usual accessories such as transmitter, receiver, batteries, powerbox and possibly other small accessories.
